Nvidia / Dell A100 40gb Baseboard X4- 700T5 / 935-22687-0130-000
🧠 Product Overview
The NVIDIA A100 Tensor Core GPU is a flagship data center accelerator built on the Ampere architecture, delivering groundbreaking performance for AI, high‑performance computing (HPC), data analytics, and scientific modeling Artfield Institute+1Accelerator+1Accelerator+2NVIDIA+2NVIDIA+2.
Packaged by Dell as a 4‑GPU “x4 Baseboard”, this modular card integrates four A100 GPUs to deliver massive parallelism in a single PCIe 4.0 or SXM4 enclosure—ideal for enterprise servers like Dell PowerEdge and HGX platforms.
⚙️ Key Specifications
GPU & Memory
Architecture: NVIDIA Ampere, GA100 core
Tensor Cores: Third‑generation (432 cores per GPU) Artfield InstituteDell Technologies Info Hub+6IT_Creations+6XByte+6
CUDA Cores: 6,912 per GPU Dell Technologies Info Hub+6IT_Creations+6Accelerator+6
Memory: 40 GB HBM2 (per GPU), total 160 GB across board
Bandwidth: Up to 1,555 GB/s per GPU NVIDIA+4IT_Creations+4Accelerator+4NVIDIA+1NVIDIA+1
Performance
FP64: 9.7 TFLOPS (19.5 TFLOPS tensor)
FP32 (TF32): 19.5 TFLOPS (312 TFLOPS with sparsity)
FP16/BF16: 312 TFLOPS (624 TFLOPS with sparsity)
INT8/INT4: Up to 624 TOPS / 1,248 TOPS Artfield Institute+6IT_Creations+6NVIDIA+6NVIDIA+1NVIDIA+1
Thermal and Power
TDP: 250 W per GPU, air‑cooled passive heatsink Artfield Institute+7NVIDIA+7IT_Creations+7
Multi‑GPU NVLink Bridge support: up to 600 GB/s inter‑GPU bandwidth IT_Creations+3NVIDIA+3NVIDIA+3
Form Factor
Board format: Dual‑slot, full‑height/full‑length (10.5″), PCIe Gen 4.0 ×16
Includes NVLink bridge and extender options for server compatibility XByte+3NVIDIA+3IT_Creations+3
Advanced Features
Multi‑Instance GPU (MIG): Split each GPU into up to seven isolated instances, optimizing resource utilization Artfield Institute+5NVIDIA+5NVIDIA+5
ECC Memory: Hardware-level error correction, enabled by default on all GPUs IT_Creations
NVLink & NVSwitch Ready: High-bandwidth interconnects in multi-GPU setups NVIDIA+1XByte+1
🎯 Ideal Use Cases
AI/ML Training & Inference: Exceptional throughput for models like BERT and GPT, offering up to 20× acceleration over previous-generation GPUs NVIDIA+2NVIDIA+2Dell Technologies Info Hub+2
HPC & Scientific Simulation: Double-precision tensor cores (FP64) and high memory bandwidth dramatically reduce compute times IT_Creations+5NVIDIA+5Dell Technologies Info Hub+5
Multi-Tenant GPU Environments: MIG enables independent, isolated compute slices for concurrent workloads
🔧 Dell Platform Integration
Designed for Dell PowerEdge servers (e.g., XE8545, R7525) and HGX/DGX systems
Optimized for PCIe 4.0 and NVLink interconnects on supported Dell infrastructure Dell Technologies Info Hub+1XByte+1
✅ Summary
The NVIDIA / Dell A100 40 GB Baseboard x4 offers a turnkey solution for deploying four A100 GPUs in a single module, combining world-class performance, efficiency, and flexibility:
Unmatched AI training/inference capabilities, with multi‑precision support
Robust memory, ECC protection, and GPU partitioning via MIG
Seamless integration into Dell’s high-end server stacks
Ideal for enterprises seeking scalable GPU acceleration for AI, HPC, and analytics.
🧠 Product Overview
The NVIDIA A100 Tensor Core GPU is a flagship data center accelerator built on the Ampere architecture, delivering groundbreaking performance for AI, high‑performance computing (HPC), data analytics, and scientific modeling Artfield Institute+1Accelerator+1Accelerator+2NVIDIA+2NVIDIA+2.
Packaged by Dell as a 4‑GPU “x4 Baseboard”, this modular card integrates four A100 GPUs to deliver massive parallelism in a single PCIe 4.0 or SXM4 enclosure—ideal for enterprise servers like Dell PowerEdge and HGX platforms.
⚙️ Key Specifications
GPU & Memory
Architecture: NVIDIA Ampere, GA100 core
Tensor Cores: Third‑generation (432 cores per GPU) Artfield InstituteDell Technologies Info Hub+6IT_Creations+6XByte+6
CUDA Cores: 6,912 per GPU Dell Technologies Info Hub+6IT_Creations+6Accelerator+6
Memory: 40 GB HBM2 (per GPU), total 160 GB across board
Bandwidth: Up to 1,555 GB/s per GPU NVIDIA+4IT_Creations+4Accelerator+4NVIDIA+1NVIDIA+1
Performance
FP64: 9.7 TFLOPS (19.5 TFLOPS tensor)
FP32 (TF32): 19.5 TFLOPS (312 TFLOPS with sparsity)
FP16/BF16: 312 TFLOPS (624 TFLOPS with sparsity)
INT8/INT4: Up to 624 TOPS / 1,248 TOPS Artfield Institute+6IT_Creations+6NVIDIA+6NVIDIA+1NVIDIA+1
Thermal and Power
TDP: 250 W per GPU, air‑cooled passive heatsink Artfield Institute+7NVIDIA+7IT_Creations+7
Multi‑GPU NVLink Bridge support: up to 600 GB/s inter‑GPU bandwidth IT_Creations+3NVIDIA+3NVIDIA+3
Form Factor
Board format: Dual‑slot, full‑height/full‑length (10.5″), PCIe Gen 4.0 ×16
Includes NVLink bridge and extender options for server compatibility XByte+3NVIDIA+3IT_Creations+3
Advanced Features
Multi‑Instance GPU (MIG): Split each GPU into up to seven isolated instances, optimizing resource utilization Artfield Institute+5NVIDIA+5NVIDIA+5
ECC Memory: Hardware-level error correction, enabled by default on all GPUs IT_Creations
NVLink & NVSwitch Ready: High-bandwidth interconnects in multi-GPU setups NVIDIA+1XByte+1
🎯 Ideal Use Cases
AI/ML Training & Inference: Exceptional throughput for models like BERT and GPT, offering up to 20× acceleration over previous-generation GPUs NVIDIA+2NVIDIA+2Dell Technologies Info Hub+2
HPC & Scientific Simulation: Double-precision tensor cores (FP64) and high memory bandwidth dramatically reduce compute times IT_Creations+5NVIDIA+5Dell Technologies Info Hub+5
Multi-Tenant GPU Environments: MIG enables independent, isolated compute slices for concurrent workloads
🔧 Dell Platform Integration
Designed for Dell PowerEdge servers (e.g., XE8545, R7525) and HGX/DGX systems
Optimized for PCIe 4.0 and NVLink interconnects on supported Dell infrastructure Dell Technologies Info Hub+1XByte+1
✅ Summary
The NVIDIA / Dell A100 40 GB Baseboard x4 offers a turnkey solution for deploying four A100 GPUs in a single module, combining world-class performance, efficiency, and flexibility:
Unmatched AI training/inference capabilities, with multi‑precision support
Robust memory, ECC protection, and GPU partitioning via MIG
Seamless integration into Dell’s high-end server stacks
Ideal for enterprises seeking scalable GPU acceleration for AI, HPC, and analytics.
New- No Heatsinks
